BF297 Transistör NPN-N-Channel Transistor TO-92

BF297 Transistör NPN-N-Channel Transistor TO-92

Type Designator: BF297

Material of Transistor: Si

Polarity: NPN

Maximum Collector Power Dissipation (Pc): 0.625 W

Maximum Collector-Base Voltage |Vcb|: 160 V

Maximum Collector-Emitter Voltage |Vce|: 160 V

Maximum Emitter-Base Voltage |Veb|: 5 V

Maximum Collector Current |Ic max|: 0.1 A

Max. Operating Junction Temperature (Tj): 150 °C

Transition Frequency (ft): 95 MHz

Collector Capacitance (Cc): 10 pF

Forward Current Transfer Ratio (hFE), MIN: 30

Noise Figure, dB: -

Package: TO226
